Single cylinder、4-stroke、air-cooled、vertical、diesel engine
Starting fashion
Manual or electric start
Fuel tank capacity(L)
2.5
3.5
5.5
Pump Set
Continuous running time(h)
2.5
2.0
2.0
N.W./G.W(kg)
35/38
52/55
69/72
Dimension LxWxH(mm)
490x410x510
570x450x550
645x470x600
Package size LxWxH(mm)
500x420x525
580x460x570
665x480x615
Type
IF50DI(E)
IF80DI(E)
IF100DI(E)
Pump
inch
2"
3"
4"
Rated head(m)
63
66
55
Max.suction head(m)
8
8
6
Rated capacity(m³/h)
28
39
110
Self-priming time(s/4m)
80
120
120
Engine
Mode
IF178F(E)
IF186FA(E)
IF192F(E)
Type
Single cylinder、4-stroke、air-cooled、vertical、diesel engine
Starting method
Manual or electric start
Fuel tank capacity(L)
3.5
5.5
5.5
Pump Set
Continuous running time(h)
2.0
2.0
2.0
N.W./G.W(kg)
52/57
57/62
60/65
Dimension LxWxH(mm)
570x450x550
645x470x600
645x470x600
Package size LxWxH(mm)
580x460x570
655x480x615
655x480x615
FAQ
What is your warranty period?
Our warranty period is 1 year or 1000 running hours , whichever comes first (excep the damage about spare parts of genset caused by incorrect man-made operation)
Can you use our logo?
Yes, for mass orders , we can use customer's logo.
Is there a MOQ for your generator?
No, we can accept 1 pcs for sample making for your testing and sample price will rise 10%-30% different base on different model.
What is your payment terms?
T/T 30% advance payment, the balance 70% shall be paid before shipping . L/C irrevocable / LC at sight.
