2 cylinders, 4-stroke, air cooled, direct injection
2 cylinders, 4-stroke, air cooled, direct injection
2 cylinders, 4-stroke, air cooled, direct injection
Displacement L
1.247
1.247
1.247
Engine speed(rpm)
3000/3600
3000/3600
3000/3600
Compression ratio
20:1
20:1
20:1
Rated output power[kW/rpm]
18/3000 , 19/3600
18/3000 , 19/3600
18/3000 , 19/3600
Lubrication system
Pressure splashed
Pressure splashed
Pressure splashed
Lube oil brand
Above CD SAE 10W-30,15W-40
Above CD SAE 10W-30,15W-40
Above CD SAE 10W-30,15W-40
Starting system
12 V Electric starter
12 V Electric starter
12 V Electric starter
Starting motor capacity
12V 1.7KW
12V 1.7KW
12V 1.7KW
Charging generator capacity
12V 3A
12V 3A
12V 3A
Battery capacity
12V 45AH
12V 45AH
12V 45AH
Fuel consumption 100% loading
3000rpm: 3.5 , 3600rpm: 4.0
3000rpm: 3.5 , 3600rpm: 4.0
3000rpm: 3.5 , 3600rpm: 4.0
Fuel type
Diesel 0#(summer)or-10#(winter),-35#(cold)
Diesel 0#(summer)or-10#(winter),-35#(cold)
Diesel 0#(summer)or-10#(winter),-35#(cold)
FUEL TANK CAPACITY
30L
30L
30L
Keep working times
8 Hours
8 Hours
8 Hours
FAQ
What is your warranty period?
Our warranty period is 1 year or 1000 running hours , whichever comes first (excep the damage about spare parts of genset caused by incorrect man-made operation)
Can you use our logo?
Yes, for mass orders , we can use customer's logo.
Is there a MOQ for your generator?
No, we can accept 1 pcs for sample making for your testing and sample price will rise 10%-30% different base on different model.
What is your payment terms?
T/T 30% advance payment, the balance 70% shall be paid before shipping . L/C irrevocable / LC at sight.
